| Frequency Ranges |
VHF： 66-88MHz / 136-174MHz / 216-280MHz
UHF：400-470MHz / 400-480MHz / 420-520MHz
450-520MHz |
| Channel Spacing |
Wide:25KHz / Narrow:12.5KHz |
| Output Power |
VHF:5W/1W UHF:4W/1W |
| Memory Channels |
16 |
| Voltage(DC) |
7.4V |
| Working Temperature |
-30℃ ~ +60℃ |
| Antenna Impedance |
50Ω |
|
| Audio Distortion |
≤5% |
| Modulation Type |
FM(F3E) |
| Max. Frequency Deviation |
≤5KHz |
| Adjacent Channel Selection |
≥65 dB |
| Frequency Stability |
±2.5ppm |
| Sensitivity (12dB SINAD) |
≤0.2µV |
| Audio Output power |
≥500mW |
| Spurious Radiation |
≤-60dB |
| Waterproof |
IP55 |
|
