The new generation of enhanced TETRA radios is available in basic, advanced, professional and tamper-proof configurations, allowing users to choose flexibly according to their actual needs. Using the industry’s unique noise-reducing chip technology, it has the industry’s highest waterproof and dustproof IP68 (2m, 4h) and ultra-long standby time of more than 22 hours.
-
The quality is more reliable
The products meet the triple high-grade quality standards of military standard GJB150A, military standard ML-STD-810F/G and ETSI30019-1-7. After rigorous accelerated aging testing, excellent product performance can be guaranteed in harsh environments for a long time.
-
Wider coverage
With 3W (800MHz 1.8W) RF power, the PT580HPlus effectively extends the coverage area (including basements and extended indoor coverage areas).
-
The sound quality is clearer
New Voice Noise Cancellation and Echo Cancellation technologies deliver unprecedented speech intelligibility, even in noisy environments, ensuring accurate command delivery.
-
Communication is more secure
It supports security and confidentiality methods such as authentication, air interface encryption, and end-to-end encryption, bringing high-level information security to industry users.
-
More precise positioning
PT580HPlus uses the latest positioning chip to provide higher positioning accuracy and sensitivity. Support Beidou, GPS, and GLONASS positioning services.
-
PT580H Plus parameters:
- General specifications
- UI
- Environmental indicators
| General specifications | |
|---|---|
| Frequency band range | 380-430MHZ; 405-475MHZ; 806-870MHZ; 320-380MHz *This frequency range is the hardware design frequency, and the actual frequency that can be used must strictly comply with the regulatory requirements of the country and region where it is located. The frequencies that can be used by Chinese mainland are subject to the information on the official website of the type approval of the radio transmitting equipment (https://ythzxfw.miit.gov.cn/resultQuery) and the radio frequency use license obtained by the user. |
| Dimensions (height×width× thickness) mm | 127.5 × 55 × 36.5; 127.5 × 55 × 39.5 (for BL2019) |
| weight | 368g (with battery and antenna) |
| Operating voltage | 7.4V |
| battery | Standard: 1800mAh lithium-ion battery; Optional: 2500mAh Li-ion battery; Optional: 2000mAh smart lithium-ion battery |
| Battery operating time (TMO 5/5/90 operating mode) | > 20 hours (1800mAh); > 27 hours (2500mAh); > 22 hours (2000mAh Smart) |
* The product pictures and product information involved in this webpage are for reference only, please refer to the actual product for the final time. Hytera reserves the right to modify the webpage and products without prior notice.
