The IP1100CV is a system controller for IP110H/IP100H Wi-Fi radios which communicate using a Wi-Fi network. Communication network can be made by installing one controller in the network and deploying Wi-Fi access points in various places.
-
300 Wi-Fi Radios Can Be Registered
The IP1100CV can be registered up to 300 units Wi-Fi radios (including IP100FS terminals).
When you install the IP100FS Wi-Fi radio application software, you can use your Windows® PC to communicate with handheld type Wi-Fi radios, IP110H/IP100H.
-
Up to 500 Call Addresses Programmable
The IP1100CV has the auto-provisioning function of the Wi-Fi radios. This function uses the IP1100CV as a provisioning server to provide a configuration setting to Wi-Fi radios. When a Wi-Fi radio is connected to the network, the configuration setting is automatically applied to that radio. The IP1100CV can set up to 500 call addresses for individual and group calls.
-
2.5 Gbps WAN Port and VPN Router Function
The built-in 2.5 Gbps WAN port and VPN router function* can link multiple sites with secure VPN tunnel on the Internet and extend the communication area of the Wi-Fi radio. For example, by linking between IP1100CVs using an Internet VPN, the staff in the Head Office and staff in a branch office can communicate with each other by the Wi-Fi radio.
-
19-inch Rack Mount Design
The IP1100CV can be installed in a 19-inch server rack with a 1U height and a half-width. Combined with the optional MBF-6 rack mount bracket, it perfectly fits into a 19-inch server rack.
-
Wi-Fi Radio Programmable with a Web Browser
You can set up Wi-Fi radios using a web browser. The setting data can be exported to a USB flash drive, or the saved setting data can be imported into the IP1100CV for easy maintenace.
-
Call Recording Function
The IP1100CV can record specified communication audio to an external USB flash drive.
-
Other Features
- Online firmware update capability
- A Security Slot can reduce the risk of theft
