Sale!
,

Luiton LT-348 CB Radio

Original price was: $81.99.Current price is: $77.99.

طلب عرض أسعار

  • Add products to the quote list
  • Fill out a request form
  • Get your quotation within 48 hours
- +

Reliable Communication

  • This radio works in both AM and FM modes, covering a frequency range of 26.965-27.405MHz. You can choose from three power levels—1W, 4W, or 8W—to match your communication needs.

High-Quality Reception

  • With a maximum sensitivity of 0.8μV for FM and 1.5μV for AM, this radio ensures clear reception. It also features 60dB adjacent channel selectivity to help reduce interference from other signals.

Efficient Power Management

  • The radio is designed for a 12-24V power supply, using a maximum of 3A when transmitting and only 0.3A during reception. Its compact size of 150mm x 140mm x 41mm and weight of 761g make it easy to install in vehicles.

Clear Audio Performance

  • This radio has an audio response range of 300Hz to 3kHz, providing clear sound quality during conversations. It can deliver a maximum audio power output of 3W for effective communication.

Enhanced Microphone Sensitivity

  • With a microphone sensitivity of 3mV, this radio allows for clear voice transmission without distortion, ensuring your message is heard clearly.

Additional information

Weight 1.13 kg
Dimensions 25 × 18 × 5.5 cm
Config LT-348 CB Radio
GENERAL None
Modulation modes AM/FM
Frequency range 26.965-27.405MHz
Antenna impedance 50 Ohms
Power supply 12-24V Input
Dimensions 150*140*41mm
Weight 761g
Transmission None
Frequency error +/-300HZ
Carrier power 1W/4W/8W
Transmission interference Inferior to 4nW(-54dBm)
Audio response 300HZ to 3KHZ in AM/FM
Emitted power in the adj. channel inferior to 20uW
Microphone sensitivity 3mV
Transmission Maximum current max 3A
Modulated single distortion inferior ro 5%
Reception NONE
Max sensitivity at 20dB sinad 0.8μV-113 dBm FM
1.5μV-103 dBm AM
Frequency response 300HZ to 3KHZ in AM/FM
Adjacent channel selectivity 60dB
Maximum audio power 3W
Squelch sensitivity Minimum 0.2μV -120dBm
Minimum 1mV -47dBm
Maximum current 0.3A nominal/1.2A maximum
