| Intergration |
| Frequency Range |
Can Be Suitable For Different Countries or Areas
136-174&216-280MHz (RX/TX)
136-174&350-470MHz (RX/TX)
136-174&400-480MHz (RX/TX)
136-174&420-520MHz (RX/TX)
144-146&430-440MHz (RX/TX)
144-148&222-225MHz (RX/TX)
66-88&136-174MHz (RX/TX)
66-88&400-480MHz (RX/TX)
FM: 76-108MHz (RX) |
| Memory Channels |
199 channels |
| Frequency Stability |
±2.5ppm |
| Operating Voltage |
7.4V |
| Operating Temperature |
-30℃～+60℃ |
| Waterproof |
IP 55 |
| Antenna Impedance |
50Ω |
| Dimension |
65x119x39.5(mm) |
| Weight |
253g |
|
| Transmitter |
| Frequency Stability |
±2.5PPM |
| RF Carrier Power |
UHF: 4W VHF: 5W |
| Effective Radiation Power (ERP) |
within pre-determined value ±7.5dB |
| Max. Frequency Deviation |
Channel Space: 25KHz ±5KHz
Channel Space: 12.5KHz ±2.5KHz |
| Audio Modulation |
+3dB (pre-emphasis by 6dB between 0.3-3KHz) |
| Adjacent Channel Power |
Channel Space: 25KHz ≥70 dB
Channel Space: 12.5KHz ≥60 dB |
| Spurious Radiation |
≤-30dBm |
| Inter modulation Attenuation |
≥40dB |
| Modulation Distortion |
≤10% |
| Residual FM |
≤-35dB |
| Residual AM |
≤3% |
| All specifications are according to related standard tests. Since the growing development of technology, if there is any change to the above specfication are without notice. |
|
